AiDiming PE389 0/1-10V LED Dimmer Switch – Glass Panel Knob Dimmer with IR Remote Control

Product Description

The AiDiming PE389 is a premium-grade 0/1-10V LED dimmer switch designed for intelligent lighting systems in residential and commercial environments. Featuring a modern glass panel and a metal rotary knob, this dimmer enables smooth, precise brightness adjustment and supports both active and passive dimming power supplies.

With integrated IR remote control (range up to 10 meters), users can easily switch, dim, and access 3 custom lighting scenarios remotely. Its slow on/off functionality, overheating protection, and ultra-wide 0–100% dimming range make it a safe, elegant, and reliable choice for lighting professionals.

Key Features

• Dual Signal Output – Supports both 0–10V and 1–10V dimming signal

• Smooth Knob Dimming – High-precision metal knob for seamless control

• Infrared Remote Support – ON/OFF, dimming, and 3 customizable scenarios via included remote (range < 10m)

• Slow On/Off Function – Delicate fade-in and fade-out lighting transitions

• Glass Panel with Metal Finish – Durable, modern design with strong texture

• Wide Compatibility – Works with both constant voltage and constant current dimming drivers

• Overheat Protection – Built-in safety features ensure long-term reliability

• Full Dimming Range – 0–100% brightness control

• Super Dimming Capability – Designed for deep dimming applications

• Warranty – Comes with a 5-year product warranty

Technical Specifications

• Model: PE389

• Output Voltage: 0–10V / 1–10V DC

• Max Load Power: 50mA

• Max Control Signal: 50mA

• Input Voltage: 90–250V AC

• Frequency: 50/60Hz

• Power Consumption: <5W

• Control Mode: Knob dimming with on/off switching

• Remote Control: Infrared, <10m range

• Working Temp: -20°C to 45°C (ta), up to 85°C (tc)

• Humidity: 20–95% RH, non-condensing

• Waterproof Grade: IP20

• Protection:

  • Overload: Operate within load range

  • Short Circuit: Non-repairable if shorted

  • Non-Load: No voltage output

• Dimensions: 86 × 86 × 33.2 mm (L × W × D)

• Weight: 158g ±10g

• Packing Size: 100 × 92 × 62 mm

Applications

• 0/1-10V dimming driver systems

• Smart home lighting installations

• Hotel room intelligent lighting control
