AiDiming PE-N60DA 60W DALI Dimming LED Driver (Constant Current)

Key Features

• Integrated DALI/Push/0-10V/1-10V/PWM/R DIM dimming interface

• DALI2 certification, DALI member

• Flicker-free digital control output

• Supports international AC input (200–250V)

• Multi-protection: short circuit / over-current / over-voltage

• Thermal silicone for moisture-proof and heat dissipation

• Output fast pressure terminal, safe and convenient

• Meets global lighting safety standards

• 5-year warranty

Specifications

• Model: PE-N60DA42

• Output Voltage: 9–42Vdc

• Max Output Voltage: 42Vdc

• Non-load Output Voltage: 55Vdc

• Output Current: 700–1400mA (selectable in 100mA increments via DIP switch)

• Output Power: 6.3W–58.8W

• Dimming Interface: DALI (IEC62386), Push, 0-10V/1-10V, PWM, 100kR

• PWM Dimming Frequency: >3600Hz

• Efficiency (typ): 88%

• Power Factor: PF>0.97 at 230Vac full load

• Input Voltage Range: 200–250Vac

• THD: <8% @ 230Vac full load

• Strobe Level: No flicker

• Leakage Current: <0.25mA

• Working Temp: -40~80°C

• IP Rating: IP20

• Dimensions: 160×130×43mm

• Weight: 245g ±10g

Applications

• LED monochrome light source

• Villa intelligent lighting

• Wireless intelligent lighting systems

• Museum lighting

• High-end commercial lighting

General Description

The PE-N60DA is a constant current LED driver with integrated 6-in-1 dimming capability: DALI, Push, 0-10V, 1-10V, PWM, and 100K resistor dimming. Built for professional intelligent lighting solutions, it features high power factor, ultra-deep dimming accuracy, and thermal silicone cooling for enhanced heat dissipation. Designed with DIP-switch current selection and easy wiring terminals, it fits seamlessly into DALI and KNX systems. Certified by global standards, this LED driver ensures efficient, reliable, and safe performance across diverse lighting applications.
