AiDiming PE-MC8P (V2) DALI Switch Control Panel – 8-Key Metal Button Scene Controller with Built-in Power Supply

Product Description

The AiDiming PE-MC8P (V2) is a robust DALI scene control panel designed to deliver professional-grade lighting automation. Equipped with 8 premium 5.8 aluminum alloy solid buttons and a customizable scene interface, this controller integrates seamlessly into DALI networks for both residential and commercial applications.

With a built-in DALI power supply and bus controller, it streamlines installation and control without occupying DALI addresses. It also supports multiple synchronized panels within a single DALI signal circuit, enabling simplified intelligent lighting across larger systems.

Key Features

• Standard DALI Signal – Controls brightness, color temperature, and color light

• Supports 64 Power Supplies – Manage multiple lights simultaneously

• Customizable Scene Button Names – Personalize your lighting presets

• Multi-Panel Sync Control – Install multiple panels within the same DALI circuit

• Professional DALI Integration – Designed for advanced lighting control systems

• High-Quality Components – Uses top-tier materials and imported chips

• 5.8 Aluminum Alloy Buttons – Durable, tactile, and stylish interface

• Built-in PS Bus Power Supply – Simplifies wiring, can be switched on/off

• Built-in DALI Bus Controller – Does not occupy any DALI addresses

• Minimalist Design – Elegant matte black finish, ideal for modern interiors

Technical Specifications

• Model: PE-MC8P (V2)

• Output Voltage: 17.5V DC ±5%

• DALI PS Voltage: 12–22V DC

• Control Current: 125mA

• Dimming Range: 0–100%

• Dimming Interface: DALI (IEC62386)

• Load Capacity: 64 DALI Addresses

• Input Voltage: 200–250V AC

• Frequency: 50/60Hz

• Touch Keys: 8

• Scene Function: Supports 6 custom scenes

• Working Temp.: -20°C to 45°C (ta), up to 80°C (tc)

• Humidity: 20–95% RH (non-condensing)

• Storage Temp./Humidity: -40°C to 80°C, 10–95% RH

• Withstand Voltage: 3750V AC

• Isolation Resistance: 100MΩ @ 500VDC/25°C/70%RH

• Dimensions: 86 × 86 × 33 mm

• Weight: 185g ±10g

• Packing: Box

Applications

• Dual-color and monochrome DALI lighting

• RGBCW lighting control

• Villa smart lighting systems

• Museum and gallery lighting

• High-end commercial installations

• Professional lighting upgrades and retrofits
